TNK-400X.75
Available in forces between 6,655 N (1,496 lbf) and 6,730 N (1,513 lbf). TNK 400 are ideal for high performance.
A variety of mounting options provides flexiblility in die design. TNK 400 are available as self-contained or in a hosed system.
Diagram / specifications section
Preview
| L | Minimum Length (in) | 2.75 |
| S | Stroke Length (in) | 0.75 |
| Y | Total Length (in) | 3.5 |
Item specifications
- Charging Pressure (Psi)2175
- End Force At Full Stroke (LBF)1508
- Force Increase By Temperature Percent Per (°F)0.17
- Gas Volume (CuF)0.0003
- Initial Force at max. pressure (lbf) 885
- Max Charging Pressure (Psi)2175
- Max Piston Rod Velocity (FtMin)114.173
- Max. Operating Temperature (F)176
- Min Charging Pressure (PSI)362
- Min. Operating Temperature (F)32
- Recommended Max Strokes Per Minute~ 80-100
